WP-150V-25-R - Weldcraft A-150 Modular Valve Air-Cooled TIG Torch Package, 25ft

Weldcraft WP-150V-25-R: A-150 Modular Air-Cooled TIG Torch Specs

The Weldcraft A-150 Modular Valve TIG Torch is a premium air-cooled solution rated for 150 amps DC and 105 amps AC. This specific configuration, SKU WP-150V-25-R, includes a 25-foot (7.6 meter) one-piece rubber power cable, offering superior durability and resistance to heat and abrasion compared to standard vinyl cables. The torch body features a modular interface that accepts various heads, allowing the operator to configure the torch into multiple styles (such as the included 1726 and 9-70 head styles) to suit specific joint geometries.

Key Technical Features:

• Gas Control Valve: The integrated valve on the torch body provides precise on/off control of shielding gas, enabling TIG welding operations on power sources lacking internal gas management.
• Modular Flexibility: The included flex neck element allows the torch head to be bent to accommodate difficult welding positions, reducing operator fatigue and improving weld quality in restricted access areas.
• Cooling Efficiency: Designed with a heavy-duty copper construction, the A-150 series maximizes current transfer and heat dissipation, ensuring consistent performance at the rated duty cycle.

This kit is supplied with the torch body, handle, valve, flex neck, and power cable. It is compatible with standard Weldcraft 2 Series consumables, ensuring that collets, collet bodies, and nozzles are easily sourced. The modular design not only enhances versatility but also minimizes inventory costs, as a single torch body can serve the function of multiple fixed-head torches. Ideal for maintenance, repair, and field construction applications.
