01V046 - Walter Walter Carbide Burr Sg-3 Dc

Packaging: 1 per each
$65.08/ea $57.17/1 per each only $57.17/eaSave 12%

Usually ships within 3-5 business days

OVERVIEW

The Welder's Choice for Deburring and Finishing

For welders and fabricators, surface preparation and finishing are just as important as the weld itself. The Walter SG-3 Double Cut Carbide Burr (01V046) is built to tackle the toughest grinding tasks found in welding shops. Made from premium tungsten carbide, this rotary file cuts through steel and stainless steel with ease, making it perfect for cleaning up weld beads, deburring cut edges, or enlarging bolt holes in fabrication projects.

The SG-3 "Pointed Tree" geometry allows you to get into tight corners and V-grooves that flat grinding wheels simply can't reach. This makes it an invaluable tool for pipe welders and structural fabricators who need to prep joints or clean up root passes. The Double Cut flute design creates smaller chips, which means the tool cuts faster and smoother than single-cut alternatives. This aggressive yet controlled cutting action gives you the ability to remove material quickly without sacrificing the quality of the surface finish.

Walter has designed these burrs to run true, with excellent balance that prevents the "chatter" often associated with lower-quality bits. This smooth operation gives you better control over the grinder, ensuring you don't accidentally gouge the workpiece. Whether you are prepping a surface for painting or cleaning up a repair job, the Walter 01V046 provides the reliability and cutting speed needed to keep your production line moving efficiently.

Additional Information
Brand:Walter Surface Technologies
Used To Grind:Steel or Stainless
Item:Carbide Burr
Shape:SG-3 (Pointed Tree)
Cut Type:Double Cut
Material:Tungsten Carbide
Application:Deburring, Enlarging, Finishing
Packaging Description:1 per each

INCLUDED

  • 1 x Walter SG-3 Double Cut Carbide Burr

APPLICATIONS

  • Deburring cut metal edges
  • Enlarging holes and slots
  • Smoothing weld seams and joints
  • Surface preparation on steel and stainless steel
  • Fine finishing in hard-to-reach areas
  • Contouring and shaping metal parts

FAQ

SG-3 is the industry standard code for the shape and size of the burr. It refers to a Pointed Tree shape, typically used for contouring and reaching into tight angles.

A Double Cut burr features flutes cut in two intersecting directions (diamond pattern). This design allows for faster material removal, smaller chips, and a smoother finish compared to single cut burrs.

Yes, the Walter 01V046 is made from high-grade tungsten carbide and is specifically designed to be effective on tough metals like stainless steel and steel.

This carbide burr is designed for use with pneumatic or electric die grinders.

Perfect concentricity ensures the burr spins true without wobbling. This reduces vibration, prevents premature wear on the tool and grinder, and provides a better finish.

While it can cut aluminum, Double Cut burrs may clog (load up) with soft non-ferrous metals. An Aluminum Cut (single wide flute) burr is generally recommended for aluminum to prevent clogging.

Tungsten carbide is significantly harder and more heat-resistant than high-speed steel (HSS), allowing it to cut faster and last much longer, especially on hard metals.

CATALOGUE & SPEC SHEETS

Spec Sheet
