01V047 - Walter SM-1 Double Cut Tungsten Carbide Rotary Burr

Packaging: 1 per each
$51.32/ea $45.07/1 per each only $45.07/eaSave 12%

Usually ships within 3-5 business days

OVERVIEW

Chew Through Metal with Confidence

When you have a rough weld to smooth out or a hole that needs to be just a little bit bigger, you need a tool that bites. The Walter Carbide Burr SM-1 DC is your go-to solution for aggressive yet controlled metal removal. Built for welders and fabricators who don't have time to waste on dull bits, this tungsten carbide burr is designed to eat through steel and stainless steel without skipping a beat. The SM-1 conical shape is perfect for getting into those hard-to-reach corners or prepping a bevel in a tight spot where a grinding wheel just won't fit.

What sets this burr apart is the Double Cut design. Instead of just gouging the metal, the cross-cut teeth slice it away in tiny chips. This means the tool is easier to control—it won't try to "climb" or jump out of the cut like single-cut burrs often do. You get a smoother finish right off the bat, reducing the amount of sanding or polishing you need to do afterward. Plus, the double cut action reduces heat buildup, keeping the burr sharper for longer, even when you're grinding on tough stainless steel.

Vibration is the enemy of any die grinder operator. A wobbly burr numbs your hands and ruins your work. Walter manufactures these burrs to be perfectly balanced, so they run smooth and true. This protects your expensive die grinder from wear and tear and keeps your hands steady for precision work. Whether you are deburring a fresh cut, cleaning up a root pass, or enlarging a bolt hole, the Walter SM-1 Double Cut Burr delivers the performance you need to get the job done right and move on to the next one.

Additional Information
Brand:Walter Surface Technologies
Item:Carbide Burr
Used To Grind:Steel or Stainless
Packaging Description:1 per each
Shape:SM-1 (Cone)
Cut Type:Double Cut
Material:Tungsten Carbide
Head Diameter:1/4"
Length Of Cut:1/2"
Shank Diameter:1/4"

INCLUDED

  • 1x Walter Carbide Burr SM-1 DC (01-V 047)

APPLICATIONS

  • Deburring cut edges on steel and stainless steel
  • Enlarging holes and slots
  • Finishing welds in confined spaces
  • Contouring and shaping metal parts
  • Removing material in hard-to-reach corners

FAQ

The SM-1 is a pointed cone shape. It typically measures 1/4 inch in diameter at the widest point and has a 1/2 inch length of cut, making it ideal for tight corners and angled entries.

Double Cut means the burr has two sets of grooves cut across each other. This creates smaller chips (instead of long slivers), allows for faster material removal, and provides a smoother finish with better operator control.

While it can cut aluminum, Double Cut burrs may clog (load up) with soft non-ferrous metals. For aluminum, a single cut or specifically designed 'Alu-Cut' burr is generally recommended to prevent clogging.

This burr features a standard 1/4-inch shank and is designed for use with pneumatic or electric die grinders. Ensure your tool is rated for the appropriate RPM range for carbide burrs.

Yes, the tungsten carbide material and double cut geometry are excellent for use on stainless steel, providing aggressive removal without rapid dulling.

Concentricity ensures the burr spins perfectly true. This prevents 'chatter' or vibration, which extends the life of the burr, protects the grinder's bearings, and produces a higher quality surface finish.

The 01V047 has a standard 1/4-inch shank diameter.

Tungsten carbide burrs are much harder and more heat-resistant than HSS. They last significantly longer and can cut harder materials like stainless steel effectively, whereas HSS would dull quickly.

CATALOGUE & SPEC SHEETS

Spec Sheet
Safety Data Sheet
