Walter Xcavator XX 5-Inch Ceramic Grinding Wheel Type 27

Name: Walter Xcavator XX 5-Inch Ceramic Grinding Wheel Type 27
Brand: Welders Helper
SKU: 08X502
Price: 110.30 CAD
Availability: InStock

$16.80/ea $110.30/10 per each only $11.03/eaSave 34%

Save an additional $5.52 at checkout

Join the Nation of Welders Program

SKU: 08X502 Categories: Abrasives, Grind Wheels

OVERVIEW

The Beast of Grinding Wheels

When you have a mountain of metal to move and not enough time to do it, reach for the Walter Xcavator XX™. This isn't your average hardware store grinding wheel—it's a high-performance ceramic beast designed to eat through steel and stainless steel with terrifying speed. The 08X502 model is a 5-inch wheel with a 1/8-inch thickness, giving you a focused, aggressive edge that digs in and rips off stock without bogging down your grinder.

Why choose the Xcavator XX? It's all about the grain. Walter uses a special ceramic blend that stays sharp. While other wheels get dull and require you to push harder (which burns out your arms and your grinder), the Xcavator XX does the work for you. It stays cool, cuts fast, and lasts long. It's perfect for the toughest jobs in the shop, from smoothing out heavy welds to beveling thick plate for the next pass.

Plus, it's safe for your high-end jobs. If you are working on stainless steel rails or tanks, you don't have to worry about rust or contamination because this wheel is Fe-Free. Stop wasting time with cheap wheels that turn into dust in minutes. Upgrade to the Xcavator XX and feel the difference in power and speed.

Why Welders Love It

Aggressive Bite: 1/8" profile concentrates force for faster grinding.
Long Life: Ceramic grains last significantly longer than standard wheels.
Less Fatigue: Let the wheel do the work, not your muscles.

Additional Information
Brand:Walter Surface Technologies
Diameter:5"
Thickness:0.125"
Arbor (in):7/8"
Used To Grind:Steel or Stainless
Grit:Coarse
Grain Type:Ceramic Blend
Wheel Type:Type 27
Max RPM:12250
Material Application:Steel, Stainless Steel, Hard Metal
Packaging Description:10 per each

INCLUDED

1x Walter Xcavator XX 5" Grinding Wheel

APPLICATIONS

Heavy-duty grinding of steel and stainless steel
Weld removal and blending
Beveling and chamfering plate
Grinding hard metals and alloys
Surface preparation in heavy fabrication

FAQ

The Xcavator XX is designed for steel, stainless steel, and hard metals. It is particularly effective on hardened alloys due to its ceramic grain.

Yes, the Xcavator XX is Fe-Free (free of iron, sulfur, and chlorine), ensuring it will not contaminate stainless steel or cause rust issues.

This wheel has a standard 7/8" arbor, fitting most 5-inch angle grinders.

The 1/8" thickness allows for a more aggressive bite compared to standard 1/4" wheels, enabling faster material removal rates.

No, this is a Type 27 depressed center wheel that mounts directly to the grinder using the standard flange nut or backing flange provided with your tool.

The maximum safe operating speed is typically 12,250 RPM for 5-inch wheels, but always verify with the label on the wheel itself.

Ceramic grain is harder and has a micro-crystalline structure that self-sharpens, providing a cooler cut and much longer life than standard aluminum oxide.

While 1/8" is thinner than some grinding wheels, the Xcavator XX is designed primarily for grinding. For cutting, a Zipcut or similar cutting wheel is recommended.
