Walter ZIP ALU 5-Inch Type 27 Aluminum Cutting Wheel

$10.70/ea $170.75/25 per each only $6.83/eaSave 36%

Usually ships within 3-5 business days

OVERVIEW

Stop Clogging, Start Cutting

Anyone who has tried to cut aluminum with a standard grinding wheel knows the frustration: the wheel gums up almost immediately, the grinder kicks back, and you spend more time changing wheels than actually working. The Walter ZIP ALU™ 11U152 is the solution to this common fabrication headache. Designed specifically for aluminum and non-ferrous alloys, this 5-inch cutting wheel features a proprietary abrasive blend that refuses to clog. It cuts as aggressively at the end of its life as it does at the start, saving you time and frustration.

The Walter Zip Difference

Part of the legendary ZIP™ family of abrasives, the ZIP ALU™ delivers the same lightning-fast performance you expect from Walter, but tuned for soft metals. The ultra-thin 3/64" profile slices through material with minimal resistance, leaving a clean, burr-free finish that often requires no secondary rework. Because the wheel cuts so freely, it generates significantly less heat, protecting your workpiece from discoloration and warping. This is the ideal wheel for fabrication shops, trailer repair, and marine applications where aluminum is the primary material.

Built for Tough Jobs

The Type 27 depressed center shape gives this wheel extra backbone, making it durable enough to handle the rigors of daily shop use. Whether you are trimming aluminum plate, cutting pipe, or fabricating custom brackets, the 11U152 provides the stability and safety you need. Don't settle for general-purpose wheels that compromise your efficiency. Equip your 5-inch angle grinder with the Walter ZIP ALU™ and experience the difference a purpose-built tool makes. It’s not just a cutting wheel; it’s a productivity booster that pays for itself in time saved.

Additional Information
Brand:Walter Surface Technologies
Diameter:5"
Thickness:3/64"
Arbor In:7/8"
Used To Cut:Aluminum, Non-Ferrous Metals
Wheel Style:Type 27
Max RPM:12,200
Wheel Type:Depressed Center Cutting
Bond Type:Resinoid Reinforced
Packaging Description:25 per each

INCLUDED

  • 1x Walter ZIP ALU 5" x 3/64" x 7/8" Type 27 Cutting Wheel

APPLICATIONS

  • Cutting aluminum sheets, plates, and extrusions
  • Fabrication of aluminum trailers and marine structures
  • Sizing non-ferrous piping and tubing
  • General repair work involving copper, brass, or bronze
  • Flush cutting applications requiring a depressed center hub

FAQ

The ZIP ALU is specially formulated with an abrasive blend that resists clogging (loading) when cutting soft metals like aluminum, whereas a standard ZIP wheel is optimized for steel and stainless steel.

Yes, the ZIP ALU is capable of cutting ferrous metals like steel, but for the best life and performance on steel, a standard ZIP or ZIP+ wheel is recommended.

The Type 27 (depressed center) shape provides a recessed area for the locking nut, allowing for flush cutting and providing greater rigidity compared to flat Type 1 wheels.

This wheel has a 7/8" arbor, which is the standard size for most 4.5-inch and 5-inch angle grinders.

No, this is a reinforced bonded abrasive cutting wheel designed to be mounted directly to the angle grinder using the appropriate flanges/nuts.

The wheel is 3/64" thick, which is considered an ultra-thin cut-off wheel for fast, low-heat cutting.

Yes, it is reinforced and rated for safe operation up to the maximum RPM specified on the label (typically 12,200 RPM for 5" wheels), but always check your grinder's rating.

While designed for aluminum, Walter wheels are generally manufactured to be contaminant-free, but for critical stainless work, use a wheel specifically marked 'Fe-S-Cl free' or dedicated to stainless to avoid cross-contamination from previous aluminum cuts.

CATALOGUE & SPEC SHEETS

Spec Sheet
Safety Data Sheet
