TEST - Walter Zipcut 5-Inch Type 27 Cut-Off Wheel for Steel and Stainless

Packaging: 25 in a pack
$9.80/ea $153.25/25 in a pack only $6.13/eaSave 37%

In stock

OVERVIEW

Get the Job Done Faster with Walter Zipcut Type 27

When you are in the shop or out in the field, time is money, and the Walter Zipcut 11T503 is built to save you both. This 5-inch cutting wheel features the legendary Zipcut performance—known worldwide as the "King of Cut-off Wheels"—packaged in a versatile Type 27 depressed center shape. The depressed center allows the flange nut to sit inside the wheel's profile, enabling you to get right up against a wall, floor, or another workpiece for a perfectly flush cut. It’s the problem-solver you need when a standard flat wheel just can't reach the cut line safely.

Measuring 1/16-inch thick, this wheel slices through steel and stainless steel like butter. It doesn't bog down your grinder, and it doesn't require you to lean into the tool with heavy pressure. Let the wheel do the work. The specialized grain structure is designed to self-sharpen, exposing fresh cutting edges continuously as it wears. This means the wheel cuts just as aggressively at the end of its life as it did at the start. It is particularly effective on stainless steel, where heat is the enemy; the Zipcut runs cool to prevent bluing and heat-affected zones.

Safety is paramount in welding and fabrication, and Walter doesn't cut corners. The 11T503 is heavily reinforced to resist twisting and bending, making it one of the safest thin cut-off wheels on the market. It is tough enough to handle cast iron and thick structural steel without shattering or glazing over. If you are tired of burning through cheap wheels that wobble and wear out in minutes, switch to the Walter Zipcut 11T503. It’s the reliable, heavy-duty choice for welders who care about quality results.

Applications and Compatibility

This wheel is designed for use with 5-inch angle grinders using a standard 7/8-inch arbor. It is the go-to choice for pipe fitters, ironworkers, and custom fabricators. Use it for cutting off rusted bolts flush to a surface, trimming structural beams, or sizing stainless steel plate. With the Walter Zipcut, you get straighter cuts, less burr, and more cuts per wheel, putting money back in your pocket with every spark.

Additional Information
Brand:Walter Surface Technologies
Diameter:5"
Thickness:1/16"
Arbor In:7/8"
Used To Cut:Steel & Stainless Steel
Wheel Type:Type 27 (Depressed Center)
Grit:46
Material Application:Steel, Stainless Steel, Cast Iron, Sheet Metal
Packaging Description:25 in a pack
Arbor (in):7/8

INCLUDED

  • 1 x Walter Zipcut Type 27 Cut-Off Wheel (5" x 1/16" x 7/8")

APPLICATIONS

  • Flush cutting bolts, studs, and protrusions
  • Cutting stainless steel sheet and tubing
  • Structural steel fabrication
  • Cutting cast iron pipes and components
  • General metal fabrication and repair
  • Shipbuilding and heavy equipment maintenance

FAQ

Type 1 wheels are flat and used for general cutting. Type 27 wheels have a depressed center (raised hub), which allows the locking nut to be recessed. This enables flush cutting against a surface and provides greater rigidity.

While it can cut aluminum, it is designed primarily for steel and stainless steel. For aluminum, it is recommended to use a wheel specifically designed for non-ferrous metals to prevent clogging (loading) of the wheel.

The arbor size is 7/8 inch, which is standard for most 4.5-inch and 5-inch angle grinders.

Yes, the Walter Zipcut is contaminant-free (Fe, S, Cl < 0.1%) and cuts cool, making it excellent for stainless steel as it minimizes heat buildup and discoloration.

This wheel is 1/16 inch thick, which is considered an extra-thin cut-off wheel, ideal for fast, precise cuts with minimal material loss.

No, this is a cut-off wheel designed for cutting only. It should not be used for side grinding or deburring, as thin wheels can shatter under side load. Use a grinding disc or flap disc for those tasks.

Always check the label on the wheel itself, but standard 5-inch abrasive wheels are typically rated for around 12,250 RPM. Ensure your grinder does not exceed the wheel's rating.

CATALOGUE & SPEC SHEETS

Spec Sheet
Safety Data Sheet
