Purox Style 1516 Acetylene Cutting Tip - Size 6

Precision Engineering for Superior Oxy-Acetylene Cutting

The ESAB 65Z22 (1516 Series, Size 6) cutting tip represents the pinnacle of oxy-fuel nozzle design, specifically engineered for acetylene gas applications. This nozzle is manufactured using a specialized swaging process from solid, hard-drawn copper bar stock. This method creates a mirror-smooth internal finish within the gas passages, which is critical for minimizing turbulence. A turbulent gas flow can lead to a distorted flame and ragged cuts; however, the laminar flow produced by the 1516 series ensures a sharp, defined preheat flame and a concentrated cutting stream.

Thermal management is a defining feature of this product. The one-piece copper construction provides exceptional thermal conductivity, rapidly dissipating heat away from the tip face. This characteristic is vital when performing heavy cuts—such as the 4-inch capacity offered by this Size 6 tip—where reflected heat from the workpiece can be intense. By maintaining a lower operating temperature, the tip resists the adhesion of molten slag and spatter, ensuring the orifices remain clear for longer periods. This significantly reduces the frequency of tip cleaning and replacement, optimizing operational efficiency.

Technical Specifications & Compatibility:

• Series: 1516 (General Purpose)
• Gas Type: Acetylene
• Size: #6
• Cutting Capacity: Approx. 4" (100mm)
• Construction: One-piece Hard-Drawn Copper

Designed for the professional welder, this tip fits a wide range of Purox torches, including the Type E, C-84, and CW series. The seating surfaces are precision-machined to ensure a gas-tight seal, preventing dangerous leaks and ensuring consistent pressure at the flame. Whether you are executing straight line cuts, beveling, or piercing, the ESAB 1516 #6 tip provides the control and power necessary for high-quality metalworking results.
