0558005078 - Oxweld 1566 Series Size 4 Machine Cutting Tip for Propane/Natural Gas

ESAB Oxweld 1566 Size 4: Precision Propane & Natural Gas Cutting

Upgrade your machine cutting setup with the ESAB Oxweld 1566 Series Size 4 Cutting Tip, a top-tier consumable designed for welders and fabricators who demand reliability and speed. This nozzle is specifically calibrated for use with alternative fuels—Natural Gas and Propane—offering a cost-effective solution for heavy-duty cutting without compromising on performance. Whether you are running a shape-cutting machine or a straight-line track burner, the 1566 Series delivers the thermal intensity needed to slice through 4-inch steel plate cleanly and efficiently.

The "HS" in the model designation stands for High Speed, and this tip lives up to the name. Capable of maintaining travel speeds between 7 and 13 inches per minute on 4-inch plate, it helps shops maximize their output. The nozzle features a heavy preheat flame pattern, which is essential when using propane or natural gas, as these fuels require more focused heat to initiate the cut compared to acetylene. This ensures that your machine spends less time preheating and more time cutting, improving overall operational efficiency.

Durability and ease of maintenance are built into the design. The two-piece construction—featuring a brass inner member and a copper outer shell—allows for optimal gas mixing and heat dissipation. If the tip becomes clogged from spatter or soot, it can be easily disassembled for thorough cleaning, ensuring consistent flame characteristics over a long service life. Trust in the legacy of Oxweld quality to keep your production lines moving smoothly.

Operational Parameters:

• Cutting Oxygen Pressure: 90 PSIG
• Preheat Oxygen Pressure: 25-55 PSIG
• Fuel Gas Pressure: 5-10 PSIG
• Application: Machine Cutting
