601752620 - Metabo KFM 15-10 F Variable Angle Metal Beveler

Packaging: 1 of each
$3,756.30/ea $3,130.25/1 of each only $3,130.25/eaSave 17%

Usually ships within 3-5 business days

OVERVIEW

Optimized Weld Seam Preparation

For professional welders, preparation is everything. The Metabo KFM 15-10 F Beveling Tool is specifically built to streamline the weld seam preparation process, ensuring deep, clean penetration and stronger welds. Whether you are working on flat plate or preparing pipes for joining, this tool delivers the power and precision needed to get the job done right. It features a specialized stop roller that allows for easy guiding along pipes, making it an invaluable asset for pipeline construction and pressure vessel fabrication where consistent bevels are critical.

The KFM 15-10 F is designed with the user's comfort and efficiency in mind. The bail handle can be adjusted without tools, allowing for a secure, ergonomic grip that facilitates even guiding across long workpieces. This reduces operator fatigue during extended use. With a powerful 13 Amp motor and a no-load speed of 12,500 RPM, this beveling tool aggressively removes material while leaving a smooth finish that is ready for welding. The ability to adjust the chamfer angle directly using the guide plate means you can quickly adapt to different joint configurations without hassle.

Durability is built into every component. The Metabo Long-life motor is shielded against abrasive metal dust, extending the tool's service life significantly. The included metaBOX 280 L provides a robust storage and transport solution, keeping your tool and accessories organized and protected on the job site. Included with the tool are three universal carbide indexable inserts, ensuring you are ready to work right out of the box. From breaking and rounding drilled edges to heavy-duty chamfering, the KFM 15-10 F is the welder's choice for reliable edge preparation.

Additional Information
Brand:Metabo
Item:Grinder
Packaging Description:1-per-each
Type:Accessory
Amperage:13 A
Voltage:120 V
No Load Speed:12500 RPM
Max Chamfer Height:10 mm
Chamfer Angle Range:0-90 Degrees
Cord Length:13 ft

INCLUDED

  • KFM 15-10 F Beveling Tool
  • 3 Carbide Indexable Inserts (Universal)
  • Stopper Roller
  • Screwdriver for Torx Screws 15
  • Screwdriver SW 4 with T-Handle
  • Open-Ended Spanner SW 10
  • Bow Type Handle
  • metaBOX 280 L Carrying Case

APPLICATIONS

  • Weld seam preparation on flat metal plates
  • Chamfering of pipes using the included stop roller
  • Deburring of sheet metal with complex contours
  • Breaking and rounding of drilled and punched edges
  • Creating precise chamfers up to 10mm height

FAQ

The Metabo KFM 15-10 F can produce chamfer heights up to 10 mm.

Yes, it includes a stop roller specifically designed to guide the tool along pipes for easy weld seam preparation.

The tool supports all chamfer angles from 0 to 90 degrees using a universal carbide burr.

No, it features a One-touch controller for tool-free setting of the cutting depth in 0.1 mm steps.

It features electronic overload protection, soft start, and restart protection, along with a Metabo Long-life motor with dust protection.

Yes, the product comes with a metaBOX 280 L for transportation and storage.

The tool is rated for 120 Volts and 13 Amps.

No, the Tacho-Constamatic (TC)-Full Wave Electronics ensure constant speed is maintained even under load.

CATALOGUE & SPEC SHEETS

Spec Sheet
