Tweco Fusion Pro 7W Water-Cooled MIG Gun, 700A, 10ft, Miller Style

$2,317.17/ea $1,680.59/1 per ea only $1,680.59/eaSave 27%

Usually ships within 3-5 business days

OVERVIEW

Stay Cool Under Pressure with the Fusion Pro 7W

As a professional welder, you know that heat is the enemy of comfort and equipment life. The Tweco Fusion Pro 7W Water Cooled MIG Gun is built to keep you welding comfortably, even when pushing 700 Amps. Unlike air-cooled guns that can become uncomfortably hot to hold during long welds, the efficient water-cooling system in the Fusion Pro 7W keeps the handle and neck cool, significantly reducing hand fatigue and perspiration. This allows you to maintain focus on the puddle and weld quality, rather than the heat radiating from your torch.

The ergonomics of the Fusion Pro handle are designed with the welder in mind. It features a balanced weight distribution and soft-grip inserts that provide a secure, comfortable hold, reducing wrist strain over long shifts. The knuckle-joint at the handle base allows for improved flexibility and range of motion, making it easier to manipulate the gun into position without fighting the cable. The 10-foot cable length is perfect for station-based work, keeping your leads tidy and preventing tripping hazards while still giving you the reach you need around your fixture.

Consumable changes are fast and frustration-free. The Tweco Fusion contact tips and nozzles are designed for positive seating and excellent electrical conductivity, ensuring a stable arc and smooth wire feeding. Whether you are running flux-cored or solid wire, the 1/16" setup on this gun is ready to tackle heavy plate and structural welds. The Miller-style backend ensures a solid connection to your machine, so you don't have to worry about gas leaks or loose power pins interrupting your work. Upgrade to the Fusion Pro 7W and experience the difference a premium water-cooled gun makes.

Additional Information
Brand:Tweco
Length:10 ft
Back End:Miller
Wire Size:1/16"
Amperage:600
Cooling Method:Water Cooled
Duty Cycle:100% @ 700A (CO2)
Neck Angle:45 Degree
Series:Fusion Pro 7W
Connection Type:Miller Style
Packaging Description:1 per ea

INCLUDED

  • 1 x Tweco Fusion Pro 7W Water-Cooled MIG Gun (10 ft)
  • 1 x Miller Style Rear Connector
  • 1 x 45-Degree Swivel Conductor Tube
  • 1 x Contact Tip (1/16" installed)
  • 1 x Nozzle
  • 1 x Diffuser
  • 1 x Liner

APPLICATIONS

  • Heavy Industrial Fabrication
  • Structural Steel Welding
  • Shipbuilding and Offshore Construction
  • Heavy Equipment Manufacturing
  • Automotive and Transportation
  • High-Deposition Hardfacing

FAQ

The Tweco Fusion Pro 7W is rated at 700 Amps at 100% duty cycle when using CO2 shielding gas, and slightly lower when using mixed gases.

Yes, it comes with a liner, contact tip (1/16"), nozzle, and diffuser installed. You will need to ensure it is connected to a compatible water cooler and wire feeder.

This specific model (FPW7410M116) features a Miller-style backend connection.

Yes, while it comes set up for 1/16" wire, you can change the liner and contact tip to accommodate other wire sizes.

Yes, as a water-cooled gun, it must be connected to a functioning water cooling system to prevent catastrophic overheating and damage.

It uses Tweco Fusion series consumables, including Fusion contact tips, nozzles, and diffusers.

This model has a 10-foot (3-meter) cable assembly.

Yes, the conductor tube (neck) can be replaced or swapped for different angles if needed.

CATALOGUE & SPEC SHEETS

Spec Sheet
