10441138 - Tweco Fusion Pro 9W Water-Cooled MIG Torch 12ft Euro Connect

Packaging: 1 per ea
$2,553.57/ea $1,852.04/1 per ea only $1,852.04/eaSave 27%

Usually ships within 3-5 business days

OVERVIEW

Stay Cool Under Pressure

When you are pushing high amps all day, an air-cooled gun just doesn't cut it. Enter the Tweco Fusion Pro 9W Water Cooled MIG Gun. This beast is built to handle the heat so you don't have to. The water-cooling system circulates coolant right down to the nozzle, keeping the front end icy cold even during long welds. This means your contact tips last longer, the nozzle stays cleaner, and most importantly, your hand doesn't feel like it's in a toaster oven. It’s the upgrade you need if you are tired of stopping to let your gun cool down.

Comfort is king with the Fusion Pro series. The handle is designed to fit naturally in your grip, reducing hand fatigue and wrist strain over long shifts. The 12-foot cable gives you enough room to move around your workpiece without getting tangled in excess slack. Plus, this model comes ready to rock with 1/16" wire, perfect for those heavy-duty fill passes. The Euro-Kwik connector is a huge plus—snap it into any machine with a Euro port, tighten the collar, and you are ready to weld. No more messing around with complicated pin configurations or proprietary plugs.

Tweco is a name welders trust for a reason. They build gear that survives the shop floor. The Fusion Pro 9W features a tough outer jacket that resists cuts and burns, and the strain reliefs are built to handle the twisting and pulling of daily use. If you are looking for a water-cooled gun that delivers smooth wire feeding, consistent arcs, and all-day comfort, this is the tool for the job. Grab the FPW9512X116 and experience the difference a premium water-cooled torch makes in your weld quality and your comfort level.

Additional Information
Brand:Tweco
Length:12 ft
Back End:Euro
Wire Size:1/16"
Cooling Method:Water Cooled
Part Number:FPW9512X116
Connection Type:Euro-Kwik
Series:Fusion Pro
Packaging Description:1 per ea

INCLUDED

  • 1 x Tweco Fusion Pro 9W Water Cooled MIG Gun
  • 1 x 12 ft Cable Assembly
  • 1 x Euro-Kwik Connector
  • 1 x Installed Liner (1/16")
  • 1 x Contact Tip
  • 1 x Nozzle

APPLICATIONS

  • Heavy Industrial Fabrication
  • Structural Steel Welding
  • Shipbuilding and Marine Repair
  • Automotive Manufacturing
  • Pressure Vessel Fabrication
  • High-Amperage Production Welding

FAQ

This is a water-cooled MIG gun, requiring a water cooler or circulator to operate effectively.

The cable length is 12 feet (approximately 3.6 meters).

It features a Euro-Kwik style connector, which is a standard central connector used on many European and modern industrial welding machines.

It is configured for 1/16-inch (1.6mm) welding wire.

Yes, but you will likely need to install a Teflon or polymer liner and appropriate drive rolls to prevent wire feeding issues with soft aluminum wire.

It is compatible only if the machine has a Euro receptacle or if an adapter kit is installed. Many industrial machines come with Euro ports or have adapters available.

Water-cooled guns have a much higher duty cycle and are lighter and smaller for the same amperage rating, reducing operator fatigue and consumable wear.

Yes, Tweco consumables are widely available and are an industry standard.

CATALOGUE & SPEC SHEETS

Spec Sheet
