220646 - Hypertherm HPR130XD 130A Mild Steel Bevel Nozzle

Maximize Your HPR System with the 220646 Bevel Nozzle

When you are running a Hypertherm HPR130XD or HPR260XD table, you know that bevel cutting puts a unique strain on your consumables. The Hypertherm 220646 Nozzle is the genuine OEM solution designed to handle the heat and precision required for 130 Amp bevel cuts on mild steel. Don't risk your cut quality or your torch head with aftermarket knock-offs; this nozzle is built to deliver the clean, consistent edges that Hypertherm systems are famous for. Whether you are prepping plate for welding or cutting complex geometric parts, this nozzle ensures your arc stays focused and stable.

The secret behind the performance of the 220646 is the Conical Flow™ technology. Unlike standard nozzles, this design compresses the arc to increase its energy density. For the operator, this means you get a sharper cut with less dross at the bottom of the plate, saving you hours of grinding and cleanup time later. It also helps in maintaining the correct bevel angle, which is critical when parts need to fit up perfectly for subsequent welding processes. The nozzle also plays a huge role in cooling; it centers the water tube and electrode to ensure coolant flows exactly where it's needed, preventing the part from overheating and blowing out mid-cut.

This nozzle is compatible with a wide range of HyPerformance systems, including the HPR130XD, HPR260XD, HPR400, and HPR800XD. It is specifically tuned for mild steel applications. If you are cutting stainless or aluminum, you will need a different setup, but for mild steel beveling, this is the go-to part. The copper body is robust and machined to tight tolerances, ensuring it seats perfectly in the torch retaining cap every time.

To get the most out of this nozzle, always ensure your gas pressures are set according to the cut charts provided in your Hypertherm manual. A clean, dry air supply and proper pierce height will extend the life of the 220646 significantly. Keep a pack of these on hand to minimize downtime; when you see the cut quality start to degrade or the arc color change, swapping in a fresh 220646 will bring your machine back to factory-level performance instantly.
