0558102493 - ESAB TXH 201 TIG Torch Outfit, 12.5 ft, 200A, 8-Pin Remote

Technical Specification and Performance Analysis

The ESAB TXH 201 (Part Number 0558102493) is a 200-amp, air-cooled TIG torch engineered specifically for the ESAB Rebel EMP 235ic and EMP 285ic power sources. This torch utilizes a standard 26-style head configuration, making it compatible with a vast array of industry-standard consumables, including collets, collet bodies, and gas lenses. The torch is rated for a 35% duty cycle at 200 amps DC, 60% at 150 amps, and 100% at 140 amps, providing sufficient thermal capacity for medium-to-heavy fabrication tasks without the complexity of a water-cooling system.

Connection and Compatibility
The power cable is terminated with a standard 50mm solid male Dinse connector, which provides a robust electrical interface with the welder's output terminal. Shielding gas is supplied through a separate hose line featuring a 5/8"-18UNF male inert gas fitting, designed to connect directly to the solenoid output or flowmeter depending on the machine configuration. Crucially, this model includes an 8-pin Amphenol-style remote control plug. This interface enables the integrated on/off switch and potentiometer on the torch handle, allowing the operator to remotely trigger the HF start (if equipped) or Lift TIG sequence and modulate welding current dynamically during the weld cycle.

Construction and Ergonomics
The cable assembly is 12.5 feet (approximately 4 meters) in length, offering a balance between reach and cable management. The power cable is a two-piece design, separating the gas and power lines for improved flexibility. A key structural feature is the inclusion of a leather cable cover for the first 800mm (31.5 inches) extending from the handle. This knuckle-joint transition zone significantly improves torch flexibility, allowing for easier manipulation in out-of-position welds. The torch body itself is constructed with high-grade silicone rubber insulation that resists cracking and electrical breakdown under high thermal loads.

Consumable System
As a 26-style torch, the TXH 201 supports tungsten electrode diameters ranging from .040" (1.0mm) to 5/32" (4.0mm). The outfit is supplied with a starter kit that includes 1/16", 3/32", and 1/8" tungsten electrodes, matching collets and collet bodies, and No. 5, 6, and 7 alumina nozzles. It also includes both long and short back caps, allowing the torch to be configured for standard use or for access into confined spaces where the overall torch length must be minimized.
