61065007 - Arcair Extreme K3000 Gouging Torch with 10ft Cable

Arcair 61-065-007 Extreme K3000 Torch with 10' Cable

Maximize your metal removal capabilities with the Arcair Extreme K3000 Gouging Torch, complete with a 10-foot cable assembly. Identified by part number 61-065-007, this medium-duty torch is a staple in the welding and fabrication industry, renowned for its robust performance in air carbon arc gouging processes. Rated for a maximum of 600 Amps, the K3000 bridges the gap between light-duty repair work and heavy-duty foundry applications, offering a balanced solution for most general purpose gouging needs.

The "Extreme" designation signifies Arcair's commitment to innovation. This model features an improved air valve and head design that ensures consistent air pressure and flow, critical for blowing away molten metal cleanly. The torch accommodates round electrodes ranging from 5/32" to 3/8" and flat electrodes up to 5/8", providing flexibility for different groove widths and depths. The included 10-foot cable is manufactured with high-grade copper stranding for excellent conductivity and is encased in a durable, heat-resistant cover to withstand the sparks and spatter of the gouging process.

Safety and ease of use are paramount in the K3000's design. The torch features excellent electrical insulation to protect the operator, and the cable's swivel connection allows for unrestricted movement, making it easier to maneuver the torch into difficult positions. This assembly is an ideal replacement or upgrade for older equipment, ensuring your shop maintains peak efficiency. From structural steel work to heavy equipment repair, the Arcair K3000 delivers consistent, high-quality results.

Technical Highlights

• Amperage Capacity: 600 Amps maximum.
• Cable Length: 10 feet (3 meters).
• Electrode Capacity: 5/32" (4.0mm) to 3/8" (9.5mm) round.
• Air Requirements: 80 PSI (5.6 kg/cm2) and 22 CFM (0.62 m3/min).
