01104003 - Arcair K-5 Extreme Heavy-Duty Gouging Torch Body 1250A

Packaging: pack of 1
$637.91/EA $462.65/pack of 1 only $462.65/EASave 27%

Usually ships within 3-5 business days

OVERVIEW

Maximum Power for Serious Metal Removal

When you have inches of weld to remove or massive defects to dig out, you need a torch that won't quit. The Arcair K-5 Extreme Gouging Torch is the heavy-hitter you've been looking for. Rated for a massive 1250 Amps, this torch is designed for the welder who pushes their equipment to the limit. It replaces the old 0110 model, bringing modern airflow technology and tougher materials to your daily grind. If you are working on heavy equipment, structural steel, or in a foundry, the K-5 Extreme is your best friend for moving metal fast.

Blow Slag Away Faster

Nothing slows you down like slag that won't clear. The K-5 Extreme solves this with its specialized Four-Hole Head Assembly. This design concentrates the air stream right around the electrode, blasting molten metal out of the groove instantly. This means you get a cleaner cut in one pass, saving you time on cleanup and grinding later. It runs cooler and cuts cleaner, allowing you to maintain high travel speeds even when running big 5/8" jointed carbons.

Built for the Grind

We know that gouging torches take a beating. They get dropped, dragged, and exposed to extreme heat. The K-5 Extreme is built with a heavy-duty body that insulates the operator electrically and thermally. The grip is designed to give you control without cramping your hand during long shifts. This unit is the "Torch Only" configuration, allowing you to hook it up to your existing cable assembly with a standard lug connection. Upgrade your gouging setup with the K-5 Extreme and feel the difference that 1250 amps of raw power can make.

Additional Information
Brand:Arcair
Process:Carbon Arc Gouging (CAC)
Item:Torch
Amperage Rating:1250 A
Electrode Range (Pointed):5/16" - 1/2"
Electrode Range (Jointed):5/16" - 5/8"
Electrode Range (Flat):5/8"
Head Assembly:4-Hole Optimized Air Flow
Power Connection:Conventional Lug
Packaging Description:pack of 1

INCLUDED

  • 1x K-5 Extreme Arc Gouging Torch Body
  • 1x Allen Wrench
  • 1x Owners Manual

APPLICATIONS

  • Industrial and General Fabrication
  • Structural Steel Fabrication
  • Large Component Manufacturing
  • Marine and Offshore Structure Repair
  • Pressure Vessel Fabrication
  • Hard Facing Preparation
  • Foundry Casting Finishing
  • Heavy Equipment Repair

FAQ

The Arcair K-5 Extreme is rated for a maximum of 1250 Amps, making it suitable for heavy-duty industrial gouging.

This torch accepts pointed carbons from 5/16" to 1/2", jointed carbons from 5/16" to 5/8", and 5/8" half-round (flat) carbons.

No, this SKU (01104003) is for the Torch Only. The cable assembly must be purchased separately or reused from an existing setup.

The four-hole design optimizes air flow around the electrode, providing more efficient slag removal and cleaner grooves compared to standard heads.

The K-5 Extreme (01104003) replaces the older Arcair model 0110.

It utilizes a conventional lug power connection.

Yes, the K-5 Extreme is designed to accept 5/8" half-round (flat) carbons, which are often used for skimming and washing applications.

While specific requirements vary by application, standard heavy-duty gouging typically requires compressed air between 80 and 100 PSI to effectively remove molten metal.

CATALOGUE & SPEC SHEETS

Spec Sheet
