10/3 - 10/3 SOOW Portable Power Cable - Sold by the Foot

Packaging: sold by the foot
$7.02/ft $4.68/sold by the foot only $4.68/ftSave 33%

In stock

OVERVIEW

Reliable 10/3 Power Cable for Welders

Power your welding setup with confidence using this high-quality 10/3 Power Input Cable. For welders who need to extend their reach or replace a worn-out factory cord, this 10-gauge, 3-conductor wire is the industry standard for 220V welding equipment. Many factory power cords are too short for practical shop layouts; this bulk cable allows you to build a custom extension cord or install a longer primary power cable directly into your machine, giving you the freedom to weld where the work is.

The cable is built to withstand the harsh conditions of a welding shop. The thick, rubber-like jacket is resistant to sparks, oil, grease, and cuts, ensuring a long service life even when dragged across concrete floors or around sharp metal edges. Unlike stiff vinyl cords that crack in the cold, this cable stays flexible in varying temperatures, making it easy to coil up at the end of the day. It is rated for approximately 30 amps, covering a wide range of MIG, TIG, and Stick welders.

Note: This cable is sold by the foot. To build a complete extension cord, you will need to purchase compatible plugs and receptacles (such as NEMA 6-50 or L6-30) separately. Always ensure your total cable length and amperage draw are within safe limits for your specific machine to prevent voltage drop.

Additional Information
Item:Power Cable
Packaging Description:sold by the foot
Wire Gauge:10 AWG
Conductors:3
Voltage Rating:600V
Jacket Type:SOOW
Amperage Capacity:30 A
Conductor Material:Copper
Brand:Techniweld

INCLUDED

  • Sold by the foot (continuous length based on quantity ordered)

APPLICATIONS

  • Input power cables for welding machines (MIG, TIG, Stick)
  • Custom-length heavy-duty extension cords
  • Power drops for industrial machinery
  • Generator power connections
  • Outdoor portable power distribution
  • Replacement of damaged equipment cords

FAQ

10-gauge wire is typically rated for up to 30 amps in standard power transmission applications. Always check your specific equipment's manual and local electrical codes.

Yes, this type of cable (usually SOOW or similar) is designed to be water and weather-resistant, making it suitable for temporary outdoor use.

Yes, 10/3 cable is the standard choice for 220V single-phase welding extension cords and input cables for machines drawing up to 30 amps.

Yes, if you order multiple feet, it will typically be shipped as a single continuous length unless otherwise specified.

It means the cable contains three individual conductors (wires), and each conductor is 10 American Wire Gauge (AWG) in thickness.

Yes, the jacket is designed to resist oil, chemicals, and solvents commonly found in industrial environments.

Yes, this is raw bulk cable. You will need to install a compatible plug and/or receptacle for your specific application.

Yes, it features stranded copper conductors and a flexible jacket, making it easy to coil and handle compared to solid-core wire.
