Miller SubArc Twin Wire Torch 1200A Long Body

Maximize Deposition with Miller Twin Wire Technology

Upgrade your submerged arc welding setup with the Miller 1200A SubArc Twin Wire Torch - Long (SKU: 301144). Designed specifically for the Miller SubArc Digital Series, this torch is a powerhouse of productivity. It is rated for a massive 1200 amps at a 100% duty cycle, ensuring it stands up to the most demanding industrial environments without faltering. Whether you are welding railcars or heavy pressure vessels, this torch provides the thermal capacity needed for deep penetration and high-speed runs.

The twin wire configuration is a game-changer for shops looking to increase throughput. By feeding two wires into the weld pool, you can achieve significantly higher deposition rates than with standard single-wire torches. This model is engineered to handle wire diameters ranging from 3/64 inch (1.2 mm) up to 3/32 inch (2.4 mm), giving you flexibility across different welding procedures. The package comes complete with the torch body, a 2.4mm contact tip, a wire liner, and a flux nozzle, so you have the core components ready for installation.

Ergonomics and access are also addressed with the long body design. Measuring 427 mm in length, the torch allows the welding head to reach into deep weldments and tight spaces where standard torches might struggle. For the best results and smoothest wire delivery, it is highly recommended to use this torch in conjunction with a Twin Wire Straightener. Invest in genuine Miller accessories to ensure the longevity and efficiency of your automated welding systems.

Specifications:

• Rated Output: 1200 A
• Duty Cycle: 100%
• Wire Range: 3/64" - 3/32" (1.2 - 2.4 mm)
• Length: 427 mm
• Warranty: Miller True Blue Warranty (3 Months)
