K4166-7 - Lincoln Cross Country 300 Diesel Welder with Remote One-Pak

Packaging: 1 Per Ea
$39,706.59/EA $37,224.93/1 Per Ea only $37,224.93/EASave 6%

Usually ships within 3-5 business days

OVERVIEW

The Pipeliner's Choice for Power and Portability

When your livelihood depends on the quality of your welds and the reliability of your rig, the Lincoln Electric Cross Country 300 (Kubota) is the engine-driven welder that delivers. This K4166-7 One-Pak takes the hassle out of outfitting your truck by including the essential K4268-1 Wired Remote Control right out of the box. Designed by pipeliners for pipeliners, this machine addresses the specific needs of the industry: a stable arc for cellulosic stick electrodes, a compact size that maximizes truck bed space, and the rugged durability required for remote field work.

Optimized for the Right-of-Way

The Cross Country 300 is significantly smaller and lighter than many comparable machines in its class, yet it sacrifices nothing in terms of performance. Its 100% duty cycle at 300 Amps means you can weld all day without the machine quitting on you. The intuitive control panel features easy-to-use knobs for mode selection and amperage control, allowing for seamless transitions between Stick, TIG, and Wire processes. The specialized "Downhill Pipe" mode is tuned to provide the soft, controllable arc that is critical for root passes, while the CV mode handles flux-cored wire applications with ease.

Convenience and Auxiliary Power

Field work often requires more than just a welding arc. The Cross Country 300 acts as a mobile power station, providing massive AC generator power to run your grinders, beveling tools, and travel trailers. With 120V and 240V receptacles easily accessible, you have the power you need to support your entire operation. The included remote control is a game-changer for efficiency, allowing you to adjust your heat at the joint without climbing back to the truck. Combined with easy engine access for routine maintenance and a fuel-efficient Kubota diesel engine, this welder is built to keep your downtime low and your productivity high.

Additional Information
Amperage:300
Brand:Lincoln Electric
Weld Process:Engine Drive, Multi-Process
Duty Cycle:100%
Watts:11000 W
Engine Model:Kubota D902 Diesel
Fuel Type:Diesel
Auxiliary Power:11,000 Watts Peak, 9,500 Watts Continuous
Output Range:40-350A DC, 14-32V CV
Dimensions:35.9 in x 25.3 in x 60.0 in
Weight:479 kg
Packaging Description:1 Per Ea
Voltage:n/a

INCLUDED

  • Cross Country 300 Engine Driven Welder (Kubota) - K4166-1
  • Wired Remote Control - K4268-1
  • User Manual

APPLICATIONS

  • Cross Country Pipeline Construction
  • Field Maintenance and Repair
  • Structural Steel Erection
  • Oil and Gas Infrastructure
  • Mobile Fabrication Rigs
  • Process Piping

FAQ

It is powered by a liquid-cooled Kubota D902 Tier 4 Final diesel engine.

This package includes the Cross Country 300 welder (K4166-1) and the K4268-1 Wired Remote Control.

The machine is rated for 300 Amps at 32 Volts with a 100% duty cycle.

Yes, it provides 11,000 watts peak (10,000 watts continuous) of 3-phase power and 9,500 watts continuous of single-phase power.

Yes, it has a dedicated Constant Voltage (CV) mode suitable for MIG and Flux-Cored wire welding.

No, the included K4268-1 is a wired remote control. Wireless options are available separately.

The unit measures approximately 35.9 inches high, 25.3 inches wide, and 60.0 inches deep.
