Miller Deltaweld 500 MIG Welder with Running Gear & Accessories (230/460V)

Technical Specifications & Performance

The Miller Deltaweld 500 (SKU: 907787) is a DC constant voltage (CV) power source designed for GMAW (MIG), FCAW (Flux-Cored), and Air Carbon Arc Gouging processes. It delivers a rated output of 500 A at 39 VDC with a 100% duty cycle, and can push up to 600 A at a 60% duty cycle. This specific model is configured for 230/460 V, 3-phase, 60 Hz input power. The power source utilizes Miller's ArcConnect™ technology, a next-generation communication protocol that utilizes high-speed digital communication to improve weld performance and allow for easy equipment upgrades.

Internally, the machine features Fan-On-Demand™ cooling, which operates the cooling system only when necessary. This reduces the amount of airborne contaminants pulled through the machine, lowers noise levels, and reduces energy consumption. The Wind Tunnel Technology™ design further protects electrical components and PC boards from contamination, significantly extending the service life of the unit in dirty shop environments. For gouging applications, the Deltaweld 500 is capable of handling carbons up to 3/8 inch (9.5 mm) in diameter, adding versatility to its primary role as a high-deposition welding station.

This package (907787) includes the power source, running gear, and an accessory kit. The accessory kit typically comprises 4/0 welding cables, a work clamp, and gas regulation equipment, ensuring the secondary circuit is rated for the machine's maximum output. It is designed to pair with Intellx™ or Intellx™ Pro wire feeders. The interface is streamlined for ease of use, featuring large digital meters that are easy to read from a distance and simple controls that reduce setup time and operator error.

System Specifications

• Input Power: 230/460 V, 3-Phase, 60 Hz
• Rated Output: 500 A at 39 V, 100% Duty Cycle
• Amperage Range: 30 – 650 A
• Voltage Range: 10 – 38 V
• Dimensions (H x W x D): 28.5 in x 16.5 in x 31.5 in (Power Source Only)
