The Thermal Dynamics Cutmaster 40 (1-4000-1) by ESAB is a premier 40-amp plasma cutting system engineered for versatility and reliability. It is the ideal solution for automotive bodies, general fabrication, and maintenance applications requiring a compact yet powerful cutting tool. The machine operates on single-phase power with a broad input range of 110V to 240V, making it compatible with both standard household outlets and industrial power grids.
This unit delivers a rated output of 40 Amps at 40% duty cycle (at 230V), providing sufficient power for continuous cutting of 1/2-inch mild steel. For lighter tasks, it offers 100% duty cycle at 20 Amps. The gas system requires compressed air at a flow rate of 300-500 cfh and a pressure range of 90-125 psi. The unit is generator-friendly, with a recommended generator size of 8.0 kW for full output performance.
The included SL60 1Torch sets the standard for plasma torches, featuring a 16-foot lead and an ergonomic handle. The ATC Quick Disconnect allows for rapid torch removal, which is essential for protecting the torch during transport or switching between machine and hand torches. The package comes complete with a work cable, clamp, and a spare parts kit containing the latest Black Series consumables for extended service life.
The Cutmaster 40 is not just a machine; it is a complete cutting package. It includes power adapters for 50A to 20A and 20A to 15A connections, ensuring you can hook up to various power receptacles right out of the box. With its rugged case, three lift points, and lightweight footprint, it is ready to tackle the most demanding jobs in the shop or out in the field.
| Additional Information |
|---|
| Brand:ESAB |
| Amperage:40 |
| Voltage:110/240 V |
| Weld Process:Plasma Cutting |
| Duty Cycle:40% |
| Packaging Description:1 of each |
| Process Type:Plasma Cutting |
| Input Voltage:110 V, 240 V |
| Output Amperage Range:15 - 40 A |
| Recommended Cut Capacity:1/2 inch (12 mm) |
| Maximum Severance:1 inch (25 mm) |
| Gas Requirements:Compressed Air |
| Gas Pressure:90-125 psi (6.2-8.6 bar) |
| Gas Flow:300-500 cfh (142-235 l/min) |
| Torch Model:SL60 1Torch |
| Torch Cable Length:16 ft (4.9 m) |
| Weight:10 kg (22 lbs) |
| Dimensions:18.1 x 7.9 x 12.6 inches |
| Warranty:4 Years Power Supply, 1 Year Torch |
| Cutting Capacity:5/8 |
