0558102554 - ESAB Rebel EMP 285ic 120V/230V Multi-Process Welder System

Packaging: 1 of each
$6,466.77/ea $5,778.81/1 of each only $5,778.81/eaSave 11%

Usually ships within 3-5 business days

Save up to an additional $350.00 with a manufacture rebate until June 30, 2026.

OVERVIEW

The Most Powerful Rebel Yet

Unleash the full potential of your welding capabilities with the ESAB Rebel EMP 285ic Multiprocess Welder. Known for being the most powerful machine in the Rebel lineup, this welder is built to crush the most demanding jobs whether you are in the shop or out in the field. It is a complete welding system that offers true multi-process versatility, allowing you to switch between MIG, Stick, and DC TIG welding with ease. The 120V/230V dual voltage flexibility ensures you can plug in and weld almost anywhere power is available.

The Rebel EMP 285ic isn't just powerful; it's incredibly smart. The sMIG technology learns your welding style to produce a superior arc, making every weld look professional. The large, high-density TFT screen provides a clear view of your settings and includes a built-in user manual and spare parts list for on-demand support. Despite its heavy-duty output of up to 300A (max), the machine remains surprisingly portable, weighing in at 70 lbs. The unibody steel construction and industrial-grade roll cage ensure it can withstand the knocks and drops of a busy job site.

This package comes ready to weld with professional-grade accessories, including a Tweco SprayMaster Velocity MIG gun, Victor argon flowmeter, and electrode holder. The new 4-roll drive system ensures you can handle a wide range of wire diameters, from .035 inch standard wires up to 1/16 inch flux-cored wires, without skipping a beat. Whether you are welding stainless steel, mild steel, or performing maintenance on heavy agricultural equipment, the Rebel EMP 285ic provides the reliability and power you need to get the job done right.

Additional Information
Brand:ESAB
Voltage:120/230 V
Amperage:300
Weld Process:Multi-Process
Duty Cycle:40%
Phase:Single Phase
Packaging Description:1 of each
Process Type:Multi-Process, MIG, Stick, DC TIG
Input Voltage:120V, 230V
Output Range:5 - 300 A
Wire Feed Speed Range:60 - 800 ipm
Wire Diameter:0.023", 0.030", 0.035", 0.045", 0.052"
Protection Class:IP23S
Dimensions:26.5 x 11.5 x 19.5 in
Weight:32 kg
Warranty Period:3 Years

INCLUDED

  • Rebel EMP 285ic Power Source
  • Tweco SprayMaster Velocity 250A MIG Gun (15 ft / 4.5 m)
  • Tweco 200A Electrode Holder (13 ft / 4 m)
  • Tweco Ground Clamp with Leads (10 ft / 3 m)
  • Victor Argon Flowgauge Regulator
  • Gas Hose (12.5 ft / 3.8 m)
  • Atom Arc 7018 Stick Electrodes (Sample Pack)
  • ER70S-6 .035 in. Wire Spool (Sample)
  • Drive Rolls and Contact Tips
  • 120V and 230V Power Adapter Plugs
  • Operator's Manual

APPLICATIONS

  • Industrial and General Fabrication
  • Repair and Maintenance
  • Civil Construction
  • Automotive Bodies and Restoration
  • Agricultural Equipment Repair
  • HVAC and Mechanical Contracting
  • Training Schools

FAQ

The machine has a maximum output of 300 Amps and is rated at 285 Amps at 40% duty cycle when using 230V input power.

No, the Rebel EMP 285ic supports DC TIG only. It cannot TIG weld aluminum, but it can MIG weld aluminum using a spool gun.

sMIG (Smart MIG) is an exclusive ESAB feature that continuously monitors the arc and adapts to the welder's technique to provide a stable arc and superior repeatable welds.

The unit weighs 70 lbs (32 kg), making it highly portable for an industrial-class machine.

No, this specific SKU (0558102554) is the machine and accessories only. The cart is sold separately or in a different package.

It can handle solid wire up to .052 inches (1.4 mm) and cored wire up to 1/16 inches (1.6 mm).

Yes, the Rebel EMP 285ic is a dual-voltage machine and comes with adapter plugs for both 120V and 230V input power.

The package includes the power source, Tweco SprayMaster MIG gun, electrode holder, ground clamp, Victor gas regulator, gas hose, sample electrodes, sample wire spool, and drive rolls.

CATALOGUE & SPEC SHEETS

Spec Sheet
