301540 - Miller Intellx Pro Dual Wire Feeder for Deltaweld Systems

Maximize Productivity with the Miller Intellx Pro Dual Feeder

Take your Deltaweld welding system to the next level with the Miller Intellx Pro Dual Feeder (301540). This state-of-the-art bench feeder is designed to eliminate the downtime associated with swapping spools and drive rolls. By housing two independent drive mechanisms in a single unit, it allows welders to toggle between two distinct welding setups—different wire types, sizes, or shielding gases—at the flip of a switch or trigger. This is the ideal solution for shops that frequently transition between carbon steel and stainless steel, or between root pass and fill pass wires.

The "Pro" designation indicates that this feeder is equipped with advanced software capabilities that standard feeders lack. It enables Accu-Pulse™, Miller's legendary pulsed MIG process that delivers spatter-free welding and excellent puddle control, particularly on thinner materials or out-of-position welds. The feeder also supports EZ-Set technology, which simplifies parameter setting based on material thickness, ensuring that even less experienced operators can achieve high-quality welds. The wire drive system itself is robust, capable of feeding wire speeds from 50 to 780 IPM, and supports wire diameters up to 5/64 inch.

Ergonomics and maintenance have also been optimized. The drive assembly is rotatable, allowing the gun to exit at the most comfortable angle for the welder, which reduces cable strain and improves wire feed consistency. The user interface is intuitive, providing clear digital feedback on voltage and wire speed. For professional welders seeking the ultimate in versatility and arc control, the Intellx Pro Dual Feeder is the perfect companion to the Deltaweld power source.

Technical Highlights

• Compatibility: Exclusively for Deltaweld 350 and 500.
• Pulsed MIG: Native support for Accu-Pulse processes.
• Heavy-Duty Drive: Industrial-grade motors for consistent feeding.
