Miller Filtair Capture 5 Mobile Fume Extractor, 460V, 10ft Arm

Stay Safe and Productive with ZoneFlow Technology

Welding safety shouldn't come at the cost of productivity. The Miller Filtair Capture 5 Fume Extractor changes the game for professional welders by solving the biggest annoyance of fume extraction: constantly moving the arm. Thanks to exclusive ZoneFlow technology, this machine creates a capture zone three times larger than traditional extractors. You can position the arm up to five feet away from your weld and it will still pull in the fumes. This means you can weld across a larger assembly or workpiece without stopping every few minutes to readjust your equipment. Less interaction with the arm means more arc-on time and better focus on your bead.

Cleaner Air, Less Hassle

The Capture 5 isn't just about reach; it's about superior protection. It comes equipped with a FilTek XL filter that carries a MERV 15 rating, the highest class for welding fumes, ensuring that even the smallest, most dangerous particles are trapped. You won't have to worry about clogged filters killing your suction mid-shift, either. The machine features an automatic filter cleaning cycle that pulses air through the filter every time you turn the unit off, knocking dust into a collection bin. This keeps your airflow strong (900 CFM) and reduces the frequency of filter changes, saving you money on consumables in the long run.

Built for the Shop

This 460V, 3-phase unit is a beast designed for serious fabrication shops. The 10-foot arm is easy to maneuver and stays exactly where you put it without drooping, thanks to its balanced design and external joints that don't block airflow. The heavy-duty metal cabinet can take a beating, and the large rear wheels make it easy to roll over cables and uneven shop floors. Whether you are running MIG, TIG, Stick, or Flux-Cored processes, the Capture 5 keeps your breathing zone clean so you can keep working comfortably. Note: This unit requires a compressed air supply for the cleaning cycle and does not include the primary power cord.
