Hypertherm Powermax 30 AIR Plasma System with Built-in Compressor

$4,011.67/ea $3,605.31/1 of each only $3,605.31/eaSave 10%

Usually ships within 3-5 business days

OVERVIEW

Cut Anywhere, Anytime with the Powermax 30 AIR

Take your metal cutting capabilities to the limit with the Hypertherm Powermax 30 AIR, the ultimate "grab-and-go" plasma cutting system. If you are tired of hauling around heavy air compressors or being tethered to a shop air line, this is the machine you have been waiting for. The Powermax 30 AIR features a powerful, built-in air compressor, meaning you have everything you need to start cutting in one compact, 30-pound package. Whether you are working on HVAC installs on a rooftop, repairing agricultural equipment in the field, or fabricating in your garage, this system is ready to work wherever you are.

Unmatched Versatility and Ease of Use
Plug it in anywhere! Thanks to Hypertherm's Auto-Voltage technology, the Powermax 30 AIR runs on both 120V and 240V power. It comes with the necessary adapters, so you can switch between household outlets and generator power effortlessly. Despite its small size, it doesn't sacrifice power. You can cleanly cut 3/8-inch mild steel and sever up to 5/8-inch metal, making it perfect for a wide range of applications including stainless steel and aluminum. The specialized AIR T30 torch is designed to be ergonomic and tough, helping you cut longer with less fatigue.

Built for the Real World
Real-world jobs involve rust, dirt, and painted metals. The Powermax 30 AIR handles these challenges with ease using its continuous pilot arc feature, which lets you slice through rusted metal or steel grates without having to constantly re-trigger the torch. This saves you time and frustration. Backed by Hypertherm's legendary reliability and a comprehensive warranty (6 years on the power supply!), this machine is an investment in speed, quality, and convenience. Stop worrying about air hoses and start finishing jobs faster with the Powermax 30 AIR.

Additional Information
Brand:Hypertherm
Weld Process:Plasma Cutting
Voltage:120/240 V
Amperage:30
Duty Cycle:35%
Weight:30 lb
Packaging Description:1 of each
Process Type:Plasma Cutting, Gouging
Input Voltage:120 V, 240 V
Output Current:15 - 30 A
Compressor Type:Internal Integrated Air Compressor
Torch Model:AIR T30 Hand Torch
Torch Length:15 ft
Severance Capacity:5/8 inch (16 mm)
Pierce Capacity:1/4 inch (6 mm)
Engine Drive Requirement:5.5 kW for full 30A output

INCLUDED

  • Powermax 30 AIR power supply
  • AIR T30 hand torch with 15 ft (4.5 m) lead
  • Work clamp with 15 ft (4.5 m) lead
  • 240 V/20 A plug with adapters for 120 V/15 A and 240 V/20 A circuits
  • Operator and safety manuals
  • 1 standard nozzle
  • 1 electrode
  • Carrying strap

APPLICATIONS

  • HVAC and Mechanical Contracting
  • Agricultural Repair and Maintenance
  • Fire and Rescue Operations
  • General Fabrication and Construction
  • Vehicle Repair and Modification
  • Property and Plant Maintenance

FAQ

No, the Powermax 30 AIR features a built-in internal air compressor, allowing you to operate the system without an external air supply.

It has a recommended cut capacity of 3/8 inch (10 mm) and a severance capacity of up to 5/8 inch (16 mm) on mild steel.

Yes, the unit features Auto-Voltage technology and includes adapters to plug into both 120V (15A) and 240V (20A) outlets.

The duty cycle is 35% at 240 V and 20% at 120 V, measured at an ambient temperature of 104°F (40°C).

It comes with the AIR T30 hand torch with a 15-foot lead, which is specifically designed for use with this system.

Yes, it can be powered by a generator. For full 30A output, a generator with a capacity of at least 5.5 kW is recommended.

The system is highly portable and weighs approximately 29.8 lbs (13.5 kg).

Hypertherm offers a 6-year warranty on the power supply, 3-year warranty on the internal compressor, and 1-year warranty on the torch.

CATALOGUE & SPEC SHEETS

Spec Sheet
