Lincoln Tomahawk 1500 Plasma Cutter with 50 ft Hand Torch

$11,474.17/EA $10,757.04/1 Per Ea only $10,757.04/EASave 6%

Usually ships within 3-5 business days

OVERVIEW

Precision Cutting with the Tomahawk 1500

When your project demands clean, fast, and virtually dross-free cuts, the Lincoln Tomahawk 1500 Plasma Cutter is the tool of choice. This 100-amp powerhouse is designed to tackle conductive metals with ease, offering a recommended cut capacity of 1-1/4 inches. Whether you are in construction, automotive repair, or general fabrication, the Tomahawk 1500 reduces the need for secondary grinding and finishing, saving you valuable time and labor costs. The included LC105 torch with a 50-foot cable gives you the freedom to move around large workpieces effortlessly.

Ready for Any Job Site

The Tomahawk 1500 is built to go where the work is. Its rugged construction meets IP23 standards, making it suitable for both indoor workshops and outdoor field applications. The machine's ability to run on single-phase or three-phase power (200-575V) means you never have to worry about power compatibility. For remote locations, it pairs perfectly with Lincoln Electric engine-driven welders. The integrated air regulator and water separator ensure that your air supply remains consistent and dry, prolonging consumable life and maintaining cut quality.

User-Friendly Operation

Lincoln Electric has prioritized ease of use with features like the Front Panel Purge Control, which lets you set the air flow rate without initiating the arc. The rapid arc restrike capability allows for quick cutting through gaps and expanded metal, streamlining your workflow. With the "One-Pak" configuration, you get everything you need to start cutting immediately, including a consumable starter kit. Invest in the Tomahawk 1500 for a plasma cutting solution that combines power, precision, and long-term durability.

Additional Information
Brand:Lincoln Electric
Amperage:100
Duty Cycle:60%
Voltage:200-600 V
Weld Process:Plasma Cutting
Packaging Description:1 Per Ea
Input Voltage:200-575V 1/3-Phase
Output Range:30-100A
Torch Length:50 ft
Pilot Arc:Touch Start (No HF)
Dimensions:17.9 in x 11.8 in x 25.4 in
Weight:96 lbs
IP Rating:IP23
Cutting Capacity:1.25"

INCLUDED

  • Tomahawk 1500 Plasma Cutter Power Source
  • LC105 Hand Torch with 50 ft. (15 m) Lead (K2849-2)
  • Air Regulator and Pressure Gauge
  • Internal Water Separator
  • Work Clamp and 25 ft. (7.5 m) Cable
  • Input Power Cord
  • Consumable Starter Kit for LC105 Torch (KP4141-20): (2) Electrodes, (2) 100A Nozzles, (1) Swirl Ring
  • Drag Shield Cap 100A
  • Retaining Cap

APPLICATIONS

  • Steel Fabrication
  • Pipe Cutting and Beveling
  • Heavy Equipment Maintenance
  • Automotive and Transportation Repair
  • Construction and Field Erection
  • HVAC Duct Work
  • Demolition and Scrapping
  • Shipbuilding

FAQ

The Tomahawk 1500 has a recommended cut capacity of 1-1/4 inches (31.8 mm) and a severance capacity of up to 1-1/2 inches (38.1 mm) on mild steel.

No, the Tomahawk 1500 uses a Touch Start™ mechanism that initiates the plasma arc without high frequency, reducing interference with other electronics.

This machine is very versatile and can operate on 200-208/230/380/460/575 Volts, utilizing either Single Phase or 3-Phase power (50/60Hz).

Yes, this package (K3477-2) includes the LC105 Hand Torch with a 50-foot (15 m) lead.

Yes, the Tomahawk 1500 is engine drive compatible and works well with Lincoln Electric Ranger® or Vantage® series generators for remote use.

The Parts-in-Place™ system detects if the torch consumables and retaining cap are correctly installed. If they are not, the machine will not initiate an arc, ensuring operator safety.

Yes, the air regulator and pressure gauge are standard features built into the unit, along with an internal water separator.

The LC105 torch uses the KP4141 series consumables. A starter kit containing electrodes, nozzles, and a swirl ring is included in the box.

CATALOGUE & SPEC SHEETS

Spec Sheet
