907730002 - Miller XMT 350 FieldPro Multiprocess Welder, 208-575V Auto-Line

Name: Miller XMT 350 FieldPro Multiprocess Welder, 208-575V Auto-Line
Brand: Miller
SKU: MIL907730002
Price: 11520.82 CAD
Availability: InStock

Packaging: 1 PER EA

$12,819.33/ea $11,520.82/1 PER EA only $11,520.82/eaSave 10%

Save an additional $576.04 at checkout

Join the Nation of Welders Program

SKU: MIL907730002 Categories: Welding Machines, Welding Machines & Fume Extractors

OVERVIEW

Maximize Jobsite Productivity with the Miller XMT 350 FieldPro

Time is money on any construction or fabrication site, and the Miller XMT 350 FieldPro is designed to save you both. This advanced multi-process welder is built around the philosophy of keeping the operator welding rather than walking. With integrated ArcReach technology, the XMT 350 FieldPro communicates with compatible wire feeders and remotes directly through the weld leads. This means your welders can make precise parameter adjustments right at the weld joint, even if they are working dozens of stories up or hundreds of feet away from the power source. By eliminating the need to traverse cluttered jobsites to change settings, you not only boost daily throughput but also significantly reduce the risk of slip, trip, and fall injuries associated with navigating complex work zones.

The XMT 350 FieldPro is packed with intelligent features that make welding easier and more reliable. The Adjust While Welding (AWW) capability allows operators to fine-tune their settings without extinguishing the arc, providing ultimate control over the weld puddle in real-time. This is particularly beneficial for critical applications in pipe fabrication and pressure vessel work where maintaining specific heat input is vital. Furthermore, the Control Panel Lock Out feature automatically disables the power source's front panel controls when an ArcReach accessory is connected, preventing accidental or unauthorized changes by other personnel on the ground.

Beyond its smart controls, the XMT 350 FieldPro is a workhorse capable of handling a wide array of materials including aluminum, stainless steel, and specialty metals. Its compact and portable design, weighing in at just over 100 lbs, makes it easy to move around the site or mount on a rack. The unit is also compatible with the ArcReach Heater, allowing you to perform induction preheating and bakeout applications up to 600°F (315°C) using the same power source. This versatility reduces the amount of equipment needed on-site and streamlines your workflow. Invest in the Miller XMT 350 FieldPro to experience a new level of efficiency, safety, and weld quality.

Why Choose the XMT 350 FieldPro?

Reduced Downtime: Eliminate time-consuming trips to the power source for setting adjustments.
Enhanced Safety: Fewer cables on the ground and less walking through hazardous areas.
Versatile Power: Auto-Line technology allows connection to almost any power grid worldwide without manual linking.

Additional Information
Brand:Miller
Amperage:350
Voltage:208/230/460/575 V
Weld Process:Multi-Process
Packaging Description:1-per-ea
Process Type:Multi-Process, MIG (GMAW), Stick (SMAW), TIG (GTAW), Flux Cored (FCAW), Pulsed MIG (GMAW-P), RMD
Input Voltage / Phase:208-575 V, 1-Phase, 3-Phase
Net Weight:100.5 lbs
Dimensions:19 in (H) x 16 in (W) x 29 in (L)
Warranty:3 Years
Portability:Handle(s), Optional Running Gear
Connection Type:Dinse
Duty Cycle:N/A

INCLUDED

Miller XMT 350 FieldPro Power Source
Dinse-style connectors
Owner's Manual

APPLICATIONS

Construction and Infrastructure
Cross Country Pipeline
Shipbuilding and Marine Repair
Heavy Equipment Manufacturing
Process Pipe Fabrication
Pressure Vessel Fabrication
Maintenance and Repair (Field and Plant)
Welding Education and Training

FAQ

ArcReach technology allows the welding power source to communicate with wire feeders and remote controls through the weld cables. This eliminates the need for separate control cords and allows operators to adjust voltage and amperage at the weld joint.

No, it features Auto-Line technology which automatically links the power source to any primary input voltage from 208 to 575 volts, single- or three-phase, 50 or 60 Hz.

The XMT 350 FieldPro supports MIG (GMAW), Pulsed MIG (GMAW-P), Stick (SMAW), TIG (GTAW-DC), Flux Cored (FCAW), and RMD processes.

CLC ensures that the voltage set by the operator is the actual voltage delivered to the weld, regardless of cable length. It automatically adjusts the output to compensate for voltage drop over long distances.

Yes, with the Adjust While Welding (AWW) feature, operators can make parameter changes at the wire feeder or remote even while welding, allowing for immediate process control.

Yes, the XMT 350 FieldPro is compatible with the ArcReach Heater system for induction preheating and bakeout applications.

The machine is covered by Miller's True Blue Warranty for a period of 3 years.

Industrial power sources like the XMT 350 typically do not come with a pre-installed primary power cord due to the variety of input power configurations used in the field.
