S307308-045 - Hobart Quantum Arc 3 ER70S-3 MIG Wire .035 45lb Reel

Technical Overview: Hobart Quantum Arc 3 ER70S-3

Hobart Quantum Arc 3 is a solid gas metal arc welding (GMAW) wire formulated to deliver superior weld quality in high-speed applications. As an AWS A5.18 ER70S-3 class electrode, it features a chemical composition optimized for single and multi-pass welding on mild steel. The wire contains moderate levels of manganese and silicon, which act as deoxidizers to scavenge impurities from the weld puddle. This formulation helps prevent porosity and defects when welding on base metals that have light rust or mill scale, although it excels on clean surfaces where it produces a clean, flat bead with excellent tie-in.

The manufacturing process of Quantum Arc 3 prioritizes diameter consistency and surface finish. The high-quality copper coating enhances current transfer efficiency, reducing arc instability and contact tip wear. This is particularly critical in semi-automatic and robotic applications where feed interruptions can lead to costly rework. The wire is wound on a robust 45 lb steel reel, ensuring it fits standard industrial wire feeders and remains protected during transport and storage.

In terms of operating characteristics, this 0.035-inch wire supports a wide range of wire feed speeds, from moderately slow for precision work to very fast for production lines. It exhibits excellent wetting action, allowing the weld metal to flow smoothly into the toes of the weld, reducing the risk of cold lap. Compatible with both straight CO2 and Argon-rich mixtures (such as C25), the Quantum Arc 3 allows operators to fine-tune the arc for penetration or bead appearance as needed. It is an ideal choice for shops looking to balance cost, performance, and weld aesthetics.

Performance Characteristics

• Arc Stability: Smooth transfer with low spatter levels.
• Wetting: Excellent puddle fluidity for flat bead profiles.
• Feeding: Low feed force required due to superior surface finish.
• Versatility: Effective in all welding positions (with appropriate gas/settings).
